Reliability Distribution

Any numeric Entity Key that corresponds to an existing Asset.

This parameter is required and refers to the Spare. Without the Spare Entity Key, the URL will not be supported.

Displays the Spare workspace.

This parameter is required and refers to the Spare Application. Without the Spare Application Entity Key, the URL will not be supported.

Displays the Applications section.

reliability/dashboard/0

reliability/spares/2841956/spareapploverview/2841957/2841959

reliability/system/3352307/summary

reliability/system/3352307/scenario/3352304

The value for this field is calculated by the GE Digital APM system and is read-only.

This field does not appear in the grid.

A value that indicates whether or not the datapoint is excluded.

Analysis ID

Character

The name of the Reliability or Probability Distribution Analysis associated with the Distribution record.

This field is populated automatically with the value in the Analysis ID field of the Reliability or Probability Distribution record to which the Distribution record is linked.

The name of the Reliability or Probability Distribution Analysis.

You can select the value that describes a piece of equipment for which you are performing an analysis. This field is required. Reliability Analysis can be conducted on any number of equipment.

Confidence Level

Number

Indicates the percentage of uncertainty in a Goodness of Fit method.

The confidence level is used to indicate that you want the model to fit with a particular level of certainty. This value is set to 90 by default. You can enter a value between one (1) and one hundred (100).

Field that contains the specific period during which the piece of equipment is not operating during the analysis period.

This field is optional but must be numeric. If this information is available, it can be used to make the estimation more accurate. Fields like "return to service date" or "date repaired" can be used to estimate downtime.

The field that contains the last date on which the piece of equipment failed. This data can have many different descriptions (e.g., Out of Service Date, Shutdown Date, or Failure Date).

This is field is required.

The mode of failure.

Sometimes users put failed parts in this field, or even a description like "worn out" or "broke down." These descriptions can be very useful when deciding to include or not include a particular failure in the failure history for purposes of censoring.

This field is not available on the datasheet.

Fit Method

Character

The type of method used to estimate distribution parameters.

In a Reliability Distribution Analysis, this value is displayed in the Distribution Options section in the Time to Repair Distribution and Time to Failure Distribution sections. In a Probability Distribution Analysis, this value is displayed in the Distribution Options section on the Analysis Summary workspace. The method of fit for a Distribution Analysis can be either Least Squares or Maximum Likelihood Estimators (MLE).

The field that contains the date on which the piece of equipment was installed.

You can select a date field. This field is optional.

Mean

Number

The average point of the distribution. This is not necessarily the same as the average point of the dataset.

This value is calculated by the GE Digital APM system and is populated automatically. The value is calculated using distribution parameters, which vary depending on the type of distribution. For example, for a Weibuill distribution, this value is calculated using the following formula:

Median

Number

The middle point of the distribution. This is not necessarily the same as the middle point of the dataset.

This value is calculated by the GE Digital APM system and is populated automatically. The value is calculated using distribution parameters, which vary depending on the type of distribution. For example, for a Weibuill distribution, this value is calculated using the following formula:

Passed

Logical

Indicates whether the model passed the Goodness-of-Fit test or not.

A value of Yes or No that indicates if the fit test was successful (the distribution fits the data based on the test performed).

If the P-value is less than or equal to 1 minus the confidence level, the goodness of fit test has failed and this value is set automatically to No by the GE Digital APM system. Otherwise, the goodness of fit test is successful and this value is set to Yes.

Published

Logical

Indicates whether the analysis has been published.

If the analysis has been published, this value is set to True. If the analysis has not been published, this value is set to False.

P-Value

Number

The probability that the GOF Statistic is greater than the value in the Statistic field.

This value is calculated by the GE Digital APM system. The value used to determine whether the analysis passed the goodness of fit (GOF) test. The P-value is interpreted as the probability that the test statistic is due to random error. Typically, the higher the P-value, the more likely the model is appropriate and the more likely that the fit will pass the test.

Random Variable

Character

The name of the independent variable, which associates a numerical value with every event (e.g., Downtime).

This value is only populated for a Distribution record associated with a Probability Distribution Analysis. This value is populated automatically with the value you specify in the Random Variable box on the Specify the Random Variable window.

R-Squared

Number

The R-Squared Correlation Coefficient, which describes the strength of a linear model.

This value is calculated by the GE Digital APM system and populated automatically. This value measures how closely the points fall to the least squares line, providing an indication of how confident one can be of predictions made with the line. An R-Squared value greater than 0.9 is considered a good fit for linear regression.

Standard Deviation

Number

The variability of the random variable around the mean.

This value is calculated by the GE Digital APM system and populated automatically.

Statistic

Number

A value that indicates the preciseness of the fit of the data to the model.

This value is calculated automatically by the GE Digital APM system. Typically, the lower the GOF Statistic, the better the fit.

Time Units

This field contains a list of the following values:

• Hours

• Days
• Weeks
• Months
• Quarters
• Years

The time units that you select here will apply to downtime only.

Units of Random Variable

Character

The time units associated with the independent variable.

This value is associated with the value in the Variable field. This value is only populated for a Distribution record associated with a Probability Distribution Analysis. This value is populated automatically with the value you specify in the Units box on the Specify the Random Variable window.

Logical

An option that lets you send an alert to the person responsible for implementing the recommendation.

If this field is selected, the GE Digital APM system will send an alert to the person in the Assigned to Name field on the date defined in the Target Completion Date field.

This field is labeled Alert Responsible Party When Due? and is available on the Alert tab on the datasheet.

Analysis ID

Character

The ID of the analysis associated with the recommendation.

This field is populated automatically with the Record ID of the analysis to which the Reliability Recommendation record will be linked when it is saved.

Asset ID

Character

The ID for the Equipment associated with the recommendation.

You can define this field by selecting <insert ellipsis icon> and searching for the required Equipment. You can then selecting the Equipment, then select OK to link it to the Recommendation.

This field is labeled Equipment ID and is available on the General Information tab on the datasheet.

Assigned to Name

Character

The name of the person responsible for ensuring the recommendation is implemented.

This field contains a list of all Security Users in the database, presented in the following format:

<last name>, <first name>, <user ID>

This field is optional. You can select a user from the list.

This field is available on the General Information tab on the datasheet.

Author Name

Character

The name of the person proposing the recommendation.

You can select a team member from a list of current human resources.

This field is available on the General Information tab on the datasheet.

Business Impact

Character

The impact to the manufacturing process during the recommendation implementation.

You can choose this value from a list of the following options:

• Safety

• Environmental

• Production

• Economic

This field is available on the General Information tab on the datasheet.

Completed

Logical

Indicates that the recommendation is complete.

You can set this value to True to indicate that this recommendation is complete.

Completion Comments

Text

Details about the completed recommendation.

This field is required if the value in the Status field is Rejected, Cancelled,or Superseded.

This field is labeled Close-Out Comments and is available on the General Information tab on the datasheet.

Creation Date

Date

The date the recommendation was created.

This field is disabled and populated automatically with the date on which the RA Recommendation was created.

This field is available on the General Information tab on the datasheet.

Date Reviewed

Date

The date the recommendation status was changed to Reviewed.

This field is populated automatically with the current date when the Status field is updated to Reviewed.

Days before Due Date to be Notified

Number

The numbers of days prior to the target date that the email message should be sent.

This field is enabled only when the Alert Responsible Part When Due? field is set to True, in which case this field is required.

This field is labeled Days before Due Date to be Alerted and is available on the Alert tab on the datasheet.

Equipment Technical Number

Character

The technical number of the piece of equipment for which the recommendation is being made.

When you select a value in the Equipment ID field, this field is populated automatically with the value in the Equipment Technical Number field of the associated Equipment.

This field is labeled Technical Number and is available on the General Information tab on the datasheet.

Final Action Taken

Text

The actions taken to implement the recommendation.

You can define this field manually by typing a description of final actions in this field.

Final Approver Name

Character

The name of the person responsible for approving the recommendation and the associated cost.

This field contains a list of all Security Users in the database, presented in the following format:

<last name>, <first name>, <user ID>

You can select a user from the list.

This field is available on the General Information tab on the datasheet.

Frequency of Alert After Due Date

Character

The frequency after the target date that the alert will be resent.

This field is enabled only when the value in the Alert Responsible Part When Due? field is True, in which case this field is required, and you can choose a value from the list of following values:

• Never

• Daily

• Weekly

• Monthly

• Yearly

This field is available on the Alert tab on the datasheet.

Functional Location ID

Character

The ID of the Functional Location that is either linked to the Equipment that appears in the Equipment ID field or linked separately to the RA Recommendation.

This value is populated automatically if a Functional Location exists and is linked to the Equipment that appears in the Equipment ID field. You can also select <insert ellipsis icon> to search for the desired Functional Location, select it. When you select OK, the Functional Location is linked to the RA Recommendation.

This field is available on the General Information tab on the datasheet.

Implemented Date

Date

The date the recommendation was implemented.

This field is populated automatically when the RA Recommendation is implemented. When this occurs, the field becomes disabled.

This field is available on the General Information tab on the datasheet.

Implementation Alert Text

Text

Text the user can add that will be sent in the body of the alert to the assignee to remind them the recommendation must be met by the target date.

You can type the text you wish to appear in the Alert email.

This field is available on the Alert tab on the datasheet.

Mandatory Date

Date

The date by which the recommendation must be implemented.

You can select a date using the Calendar tool.

This field is available on the General Information tab on the datasheet.

Recommendation Basis

Character

Background information about why the recommendation is being made.

The reason the recommended action is needed.

You can type any necessary background information in this field.

This field is available on the General Information tab on the datasheet.

Recommendation Closure Date

Date

The date the recommendation status is changed to Implemented, Rejected, or Superseded.

This field is populated automatically with the current date when the value in the status field is changed to Implemented, Rejected, or Superseded.

Recommendation Description

Text

A detailed description of the recommendation.

You can type a description of the recommendation in this field.

This field is available on the General Information tab on the datasheet.

Recommendation Headline

Character

A brief summary of the recommendation.

You can type a brief summary of the recommendation in this field.

This field is available on the General Information tab on the datasheet.

Recommendation ID

Character

The ID for the RA Recommendation.

This field is populated automatically with a unique name (e.g., REC_888) when the recommendation is created. You can change this value if desired.

This field is available on the General Information tab on the datasheet.

Recommendation Priority

Character

A value that represents the priority or criticality level of the recommendation for implementation.

You can chose from a list of the following values:

• High

• Medium

• Low

This field is available on the General Information tab on the datasheet.

Reevaluate?

Logical

Indicates whether team members should evaluate the recommendation again.

If this check box is selected, an alert will be sent to users specified in the Reevaluation Notification List field.

This field is available on the Alert tab on the datasheet.

Reevaluation Alert Body Text

Text

The message text in the body of the reevaluation alert, which will be sent to users in the reevaluation notification list.

This field is enabled only when the Reevaluate? field check box is selected. Then the field is required.

This field is available on the Alert tab on the datasheet.

Reevaluation Notification List

Character

Individuals that will be sent to the reevaluation alert.

This field is enabled only when the Reevaluate? field is set to True. Then the field is required. You can select from a list of names with Human Resources.

This field is labeled Reevaluation Alert List and is available on the Alert tab on the datasheet.

Reevaluation Date

Date

The date on which an alert is sent out to tell the alert recipient to re-evaluate the recommendation.

This field is enabled only when the Reevaluate? field is set to True. Then the field is required. You can select a date using the Calendar tool.

This field is available on the Alert tab on the datasheet.

Required Equipment Status

Character

The operating status the piece of equipment must be under, in order for the recommendation to be implemented.

You can choose from a list of the following values:

• On-line

• Off-line

• Not Applicable

This field is available on the General Information tab on the datasheet.

Reviewer Name

Character

The first and last name of the person who should review the information in the Recommendation before the recommended action is performed.

This field contains a list of all Security Users in the database, presented in the following format:

<last name>, <first name>, <user ID>

You can select a user from a list of security users in the database.

This field is available on the General Information tab on the datasheet.

Status

Character

The status of the recommendation.

You can choose from a list of the following values:

• Approved

• Created

• Pending Review

• Reviewed

• Rejected

• Canceled

• Superseded

• In Progress

• Implemented

When the is created, the field is set to Created, but can be modified if needed. This field is required.

You can send an alert only if the Status field is set to Approved or In Progress value.

This field is available on the General Information tab on the datasheet.

Status Changed By

Character

The ID of the user who last changed value in the Status field.

This field is populated automatically when the Status field is updated.

This value does not appear on the datasheet by Work default.

Status Changed by Name

Character

The name of the person who last changed the Status field.

This field is populated automatically when the Status field is updated.

This value does not appear on the datasheet by default.

Status Date

Date

The date the Status field was most recently changed.

This field is populated automatically with the current date when the Status field is updated.

This value does not appear on the datasheet by default.

Target Completion Date

Date

The date the recommendation is intended to be implemented.

You can select a date using the Calendar tool.  This field is required.

This field is available on the General Information tab on the datasheet.

Work Order Number

Character

The ID of the work order arising from the work request.

This field is populated automatically after a notification has been created in SAP.

This value does not appear on the datasheet by default.

Work Request Equipment

Character

The ID of the Equipment in SAP that is associated with the SAP Notification that was created.

This field is populated automatically after a notification has been created in SAP.

This field is available on the General Information tab on the datasheet.

Work Request Functional Location

Character

The ID of the Functional Location in SAP that is associated with the SAP Notification that was created.

This field is populated automatically after a notification has been created in SAP.

This field is available on the General Information tab on the datasheet.

Work Request Reference

Character

The ID of the SAP Notification.

This field is populated automatically after a notification has been created in SAP.

This field is available on the General Information tab on the datasheet.

Returns the list of Reliability Distribution Analyses in the Reliability Distribution list on the RA Overview page.
