Task Bar User Interface

The Task Bar provides an overview of the currently running workflow task. Within these tasks are task steps that provide more specific information about a step, and display any user interactions that are required.

Attributes

Attribute	Value	Description
Task Name	User-defined; Preconfigured	The given name for a workflow task. Note: This name can be different from the task step name.
Expires	User-defined; Preconfigured	The scheduled duration, from the soonest to the latest time. Task expirations take precedence over task step expirations. Expired tasks can still be performed.
Priority	User-defined; Preconfigured; Numeric	The preset relevance within the workflow task configuration, from the most important to the least important.
Status bar	System-defined	Indicates the running state of the task. For more information, see Task States.
	N/A	Click this button to open and close the task grid.

User Interface

The task bar is located at the top of the Task List.
