Steam turbine life extension/replacement solutions

We can customize a solution to increase the output, improve emissions, extend asset life or enhanced operational flexibility to run at lower loads or on a non-traditional fuel.

“Built-up” rotors can experience stress corrosion cracking (SCC) in nuclear environments. Increase your reliability with our LP Monoblock rotor and section upgrades.

The LP Monoblock Rotor offers the following benefits:

• Significantly reduces SCC susceptibility in the wheel dovetails
• Reduces rotor in-service inspection scope due to boreless rotor
• Improves output and heat rate for units with the 43-inch L-0, resulting in up to 1% improvement in output

The LP section upgrade offers the following benefits:

• Significantly reduces SCC issues through new low-stress dovetail configuration
• Improves turbine output and heat rate:
  – 38- to 43-inch L-0 stage bucket delivers up to 4.5% in output improvement
  – L-0 stage bucket delivers up to 3.5% in output improvement
• Delivers reduced inspection requirements and an extended rotor inspection interval of 10 years

We have a wealth of experience in upgrading valves on many fleets and machine types. The most common way to achieve significant benefits is to upgrade the parts to improved, modern technologies.
