9F.05 CUSP upgrade
CUSP (Compressor Unit-Specific Protection) digitally estimates compressor flow-loss and schedules protection limits for 9F.05 gas turbines. Unit-specific metrics offer continuous “fired hour credit” without costly precision flow testing.
Increase performance
via continuous on-line estimation of compressor flow-loss
Up to ~3 %
reduction in pressure ratio margin possible
No tests
i.e. field compressor airflow testing
*Performance benefits vary with configuration and operating conditions.
Overview
Fast Facts
Applicable turbine models:
Time to install
10-20+ days
Inspection type
Medium
Additional info
Install during operation. Est. 1 day down for updates/test.
Benefits
What can upgrading do for you?
9F.05 gas turbines may experience increased Inlet Bleed Heat (IBH) at base load, causing higher levels of degradation than typical F-class units. This frequent IBH issue is caused by measures taken to protect against reduced performance over time through normal degradation. These measures, called operating line limit (OLL) protection, use IBH to maintain performance levels, reduce compressor operating pressure at low temperatures and protect against damaging surges or stalls. The 9F.05 controls reduce OLL over time to help protect against degradation effects, based on a fixed degradation curve.
The right solution to reduce IBH issues at a particular unit may require some or all the available options:
- Bore Plug Removal
- Fired Hour Credit (FHC)
- Compressor Unit-Specific Protection (CUSP)
- Modified S1N
How we get you there
GE Gas Power’s Compressor Unit-Specific Protection (CUSP) is the right digital technology to address turbine issues from increased inlet bleed heat (IBH) engagement, because it is based on accurate individual unit performance, not average performance curves. CUSP digitally measures compressor flow-loss and schedules compressor OLLs—based fully on gas turbine specific level of compressor fouling.
Results vary by turbine type and configuration. CUSP can provide a margin of up to 3% reduction* in pressure ratio.
*Performance benefits vary with configuration and operating conditions.
